7 BBL Brew Kettle - with Conical Bottom, Dome Top, Trub Dam, Right Orientation (Electric)
In stock
Catalog
ST-2637
Regular Price
$6,369.00
NOW ONLY
$5,790.00
This 7 bbl electric brew kettle features a trub dam to facilitate this whirlpool effect while utilizing a conical bottom for trub collection. No one wants trub in their fermenter as this can cause off flavors in your beer.
This 7 bbl brew kettle also features a tangential inlet that is used to create the whirlpool as you pump from the lowest valve and back up to the tangential inlet. This causes trub and hops to gather into a cone on the bottom of the kettle and moves clean wort to the outside.
- Material: Premium virgin 304 stainless steel
- Maximum Capacity: 340 gallons
Features of this 7 bbl electric brew kettle:
- Electric heat source
- Conical Bottom
- Domed top with manway
- 6-in. vent
- Integrated (removable) Static CIP spray ball
- Thermowell
- Tangential inlet
- Sight glass
- (5) ports for electric elements/level sensor
- (3) 1.5in. Butterfly valves, clamps/gaskets
- Includes trub dam for big hop beers.
- Non Insulated (Insulated brew kettles also available - just ask)
- Fittings oriented for the right hand side of a brewing platform
- Dimensions 45.5” diameter x 76.5”H
| Weight (lb) | 505.000000 |
|---|---|
| Retail Price | $5,790.00 |
