20 Gallon Brew Kettle - with Flat Bottom and Trub Dam (Electric)
No one wants trub in their fermenter as this can cause "off flavors" in your beer. We have designed this brew kettle to use a whirlpool effect just as in professional breweries. A tangential inlet is used to create the whirlpool as you pump from the wort outlet and back in through the tangential inlet. This causes trub and hops to gather into a cone on the bottom of the kettle.
This particular kettle also features a dish bottom to facilitate this whirlpool effect more efficiently and leave more trub and hops behind.
How Much Does it Cost to Open a Brewery? Get a FREE commercial brewing system quote.
BK20TW-TI-LL-EL1-LS1-DAM (119)
- Material: Premium virgin 304 stainless steel
- Actual Capacity: about 21 Gallons
This stainless steel brew kettle features:
- Flat Bottom
- Tangential Inlet
- Element Port
- Level Sensor Port
- Removable trub dam
- Dam height = 2.4”H and it covers a 110° range
- Laser etched gallon markings on inner wall of tank from 3 to 20 gallons
- 1.5" TC port for electric element
- 1.5" TC port for level sensor or TC type temperature probe (element and sensor not included)
- Thermowell (front of kettle)
- (2) 3/4 in. valves
- (2) 1/2 in. hose barbs
- Clamps and gaskets for provided kettle attachments
- NOTE: Customer to provide clamps and hardware for the element and level sensor ports
Still exploring options for your home brew setup? No problem. We have some of the best home brewing equipment on the market. Take a look at some of our other popular options:
- 20 Gallon Brew Kettle (with Thermowell and Laser Level)
- 20 Gallon Brew Kettle (with Thermowell and Tangential Inlet)
- 20 Gallon Brew Kettle (with Thermowell and Thermometer)
- 20 Gallon Brew Kettle (with Thermowell, Tangential Inlet, Sight Glass)
- 20 Gallon Electric Brew Kettle for Low Oxygen brewing
- 20.6 Gallon Brew Kettle for Low Oxygen brewing - On Legs (Electric)
- 21 Gallon Brew Kettle - Flat Bottom with Trub Dam (Direct Fire)
- 21 Gallon Brew Kettle - with Flat Bottom and Trub Dam (Electric)
- 21.5 Gallon Brew Kettle - Laser Level Markings, Bottom Outlet, Trub Dam (Electric)
- 21.5 Gallon Brew Kettle - with Thermowell, Tangential Inlet and Laser Level (Direct Fire)
- 21.5 Gallon Brew Kettle - with TC Port, Laser Etchings (Electric)
| Weight (lb) | 43.000000 |
|---|---|
| Retail Price | $688.00 |
