20BBL Fermenter / Unitank (Jacketed)
This 20 bbl fermenter is rated to 2bar (29 psi) and features 2 zone jacketing in its cone and on the side wall. The 2-zone glycol jacketing provides the ability to manage the cone temperature during fermentation and/or keep the beer in the cone cold as it is racked or served.
With the ability to be converted to a Unitank or brite serving tank, this 20 bbl fermenter can also help you save on floor space and increase brewing flexibility. They are also designed to save you money by shipping from our warehouse to you in a wood crate via regular freight service.
This jacketed fermenter can easily be converted to a 20 barrel Unitank using our Unitank Parts Kit. (Watch this Unitank Setup video to learn how)
- Material: Premium virgin 304 stainless steel
- Brew length (useful capacity): 20 barrels
Features of this 20 bbl conical fermenter:
- Glycol Jacketed - two zones: Cone and sidewall
- Shadowless manway for easy cleaning
- Adjustable racking arm for clear transfer
- (x1) 1.5" Sample valve for quality testing
- Adjustable feet for leveling on uneven floors or fine height adjustments
- CIP arm and 2.5" rotating CIP spray ball
- (x2) butterfly valves
- 4" dry hopping port on top
- Rated to 2BAR (29 psi)
20 bbl fermenter dimensions:
- Tank material thickness is 3mm
- Jacket and outer shell thickness is 2mm.
- Cone has 80 degree interior angle.
- Diameter = 59 inches
- Height = 122 inches
| Weight (lb) | 1285.000000 |
|---|---|
| Retail Price | $14,412.00 |
