20 BBL Fermenter / Unitank (Short, Jacketed) - PERFECT FOR LOW CEILINGS
Out of stock
Catalog
ST-20199
$13,970.00
or
Call Us503-372-9580
This Short 20 BBL fermenter features a side manway, and two zone jacketing and is designed for superior performance and temperature control. With a vertical height of 96", you can save shipping space and avoid raising your ceilings while increasing your fermentation capacity.
- Material: Premium virgin 304 stainless steel
Features of this 20 bbl conical fermenter:
- Glycol Jacketed - two zones: Cone and sidewall
- Shadowless manway for easy cleaning
- Adjustable racking arm for clear transfer
- 1.5" Sample valve for quality testing
- Back mounted pressure gauge
- Adjustable feet for leveling on uneven floors or fine height adjustments
- Can easily be converted to a Unitank using our Unitank Parts Kit (Watch this Unitank Setup video to learn how)
- CIP arm and 2.5" rotating CIP spray ball
- 2 butterfly valves
- Rated to 2-Bar (29 PSI)
- 1/2" NPT welded thermowell for contactless temperature probe
- Note: Temp probes are available for purchase separately, with options for single tank-mounted, or multi-tank wirelessly accessible fermentation temperature control panels
Dimensions:
- Tank material thickness is 3mm, jacket and outer shell thickness is 2mm. Cone has 90 degree interior angle.
- Standard dimensions are 69-in. diameter x 96-in.H. Custom dimensions are no problem - just ask.
REMEMBER : All of our jacketed conical fermenters can easily be converted to Unitanks using our Unitank Parts Kit. Please contact us directly for more details (503) 372-9580.
| Weight (lb) | 1105.000000 |
|---|---|
| Retail Price | $13,970.00 |
