10 Gallon Brew Kettle - with Tangential Inlet, Sight Glass (Direct Fire)
Like our other stainless steel brew kettles, this 10 gallon brew kettle was designed as a unique combination brew kettle and whirlpool tank, which allows you to separate the hot break from the wort prior to cast out. The dished bottom of the stainless steel brew kettle and a tangential inlet allows you to effectively stir your wort by pumping it from the regular outlet and back into the brew kettle via the inlet.
Giving you more control over the quality and consistency of your brew (beer, kombucha, cider, etc.), this 10 gallon brew kettle would be a great addition to any home brew system.
100% Sanitary | Easy to Clean | Built to Last
When you are ready for a bigger homebrew setup, check out our 1 bbl brewhouse.
BK9TW-TI-SG (166)
- Material: Premium virgin 304 Stainless Steel
- Capacity: 9.8 gallons
- Estimated number of gallons made: 5-6 gallons
Features of this 10 gallon brew kettle:
- Combination Brew Kettle/Whirlpool
- Welded-in 3" Thermowell with 1/2" NPT fitting
- Dial Thermometer
- Tangential Inlet
- Dish Bottom
- Sanitary Sight Glass
- (2) Sanitary 3/4" ball valves (5/8" ID) (Purchase an upgrade to Butterfly Valves here)
- 1.5" Tri-Clamps and gaskets
- (1) 3/8" Sanitary Hose Barb
- Diameter = 12.5"; Height = 19.5"; Steel Gauge = 1.2mm
Not quite what you are looking for? We have plenty of brew kettles to choose from. Here are some other popular options for home brewing:
- 10 Gallon Brew Kettle
- 10 Gallon Brew Kettle (with Thermowell and Thermometer)
- 10 Gallon Brew Kettle - Direct Fire (with Thermowell and Tangential Inlet)
- 10 Gallon Brew Kettle - Electric (with Tangential Inlet, Element Port)
- 15 Gallon Brew Kettle (with TC Port for Electric Element)
- 15 Gallon Brew Kettle (with Thermowell, Tangential Inlet, Trub Dam)
- 16 Gallon Brew Kettle (with Laser Markings)
- 16 Gallon Brew Kettle (with Tangential Inlet)
- 20 Gallon Brew Kettle (with Thermowell and Laser Level)
- 20 Gallon Brew Kettle (with Thermowell and Tangential Inlet)
- 20 Gallon Brew Kettle (with Thermowell and Thermometer)
- 20 Gallon Brew Kettle (with Thermowell, Tangential Inlet, Sight Glass)
- 20 Gallon Electric Brew Kettle for Low Oxygen brewing
| Weight (lb) | 25.000000 |
|---|---|
| Retail Price | $617.00 |
